Current Transducer HLSR-P series

Ref: HLSR 10-P, HLSR 16-P, HLSR 20-P, HLSR 32-P, HLSR 40-P, HLSR 50-P

Features

• Open loop multi-range current transducer
• Voltage output
• Single supply +5 V
• Galvanic separation between primary and secondary
• Low power consumption
• Compact design for through-hole PCB mounting
• Factory calibrated
• High bandwidth, very low loss magnetic core.

Advantages

• Extremely low profile: h = 12 mm
• Low foot-print
• Low offset drift
• Over-drivable Uref.

Applications

• AC variable speed and servo motor drives
• Static converters for DC motor drives
• Battery supplied applications
• Uninterruptible Power Supplies (UPS)
• Switched Mode Power Supplies (SMPS)
• Power supplies for welding applications
• Combiner box
• MPPT.
